Arduino Micro

Arduino beskrivelse

MINI USB Nano V3.0 ATmega328P CH340G 5V 16M Micro-controller board Arduino T1

Product Description

CH340G Replace FT232RL
Operating Voltage（logic level）：5V

8 analog inputs ports:A0 ~ A7
14 Digital input / output ports:TX,RX,D2 ~ D13
6 PWM ports:D3, D5, D6, D9, D10, D11
1 pairs of TTL level serial transceiver ports RX / TX
Using Atmel Atmega328P-AU MCU
There is bootloader installed in it
Support USB download and Power
Support for external 5V ~ 12V DC power supply
Support power supply by 9V battery
Support ISP download
CH340G Driver Download link : http://www.wch-ic.com/download/list.asp?id=126 OR http://www.5v.ru/ch340g.htm
IDE of arduino Download link : http://arduino.cc/en/Main/Software
